2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas

Shenzhen Huasifei Technology Co., Ltd.
Contact Now
    Buy cheap 2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas from wholesalers

    Buy cheap 2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas from wholesalers
    • Buy cheap 2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas from wholesalers
    • Buy cheap 2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas from wholesalers

    2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas

    Ask Lasest Price
    Brand Name : HUASIFEI
    Model Number : AP80
    Certification : FCC/CE/ROSH
    Price : Negotiable
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 1000PCS/45 days
    Delivery Time : 7 work days
    • Product Details
    • Company Profile

    2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas

    Dual Band 2.4GHz&5.8GHz Gigabit White Outdoor Signal Repeater With 4 Antennas


    Product Features


    1200Mbps high speed rate
    AP80 adopts Qualcomm QCA9563+QCA9886+QCA8337 chip, 2.4GHz +5.8G operating band, equipped with powerful 16M flash memory + 128M memory configuration, can support up to 80 terminals access, providing up to 1200Mbps wireless access speed, faster download and upload speed, online surfing at will.


    1000 megabit adaptive wired network interface Support POE power supply
    It provides one 10/100/1000Mbps adaptive wired network interface, which can debug the AP itself while providing network, and supports 48V POE power supply when providing data transmission when it is elected to use 48V POE power supply.

    Various functions, support AC centralized management, support Chinese SSID
    AP80 supports AC centralized management, through remote management, change configuration and other functions, so that large-scale network installation, engineering layout becomes more simple and convenient; support Chinese SSID signal name, set the WIFI name as the name of the merchant, so that customers can accurately search and connect to use; AP80 can automatically clean up the cache garbage, timing reboot, easier and more convenient to use.


    Adapt antenna with different functions according to demand
    According to different needs, the effect varies when the host is equipped with different outdoor antennas. The recommended radius of omnidirectional transmission distance is 200 meters for 8DBi omnidirectional fiberglass antenna, 300 meters for 12DBi omnidirectional fiberglass antenna, and 700 meters for 14DBi sector antenna.


    Specification


    Hardware Configuration
    Main ChipQCA9563+QCA9886+QCA8337
    Wireless Technology802.11AC, 2T2R 1200M MIMO technology
    Memory128MB DDR2 RAM
    Flash16MB
    Device Interface1 x 10/100 Mbps adaptive wired network interface (supports 48V POE power)
    AntennaExternal option
    Product SizeLength 326mm,Width 270mm,Height 79mm
    Power AdapterStandard 48 V POE power supply
    RF Parameters
    RF Characteristics802.11a/b/g/n/ac: 2.4+5.8GHz
    Korea, Japan, ETSI, FCC communication channel optional
    Modulation ModeOFDM = BPSK, QPSK, 16-QAM, 64-QAM
    DSSS = DBPSK, DQPSK, CCK
    Transmission rate1200 Mbps
    Software characteristics
    Operating modeGateway Mode/AP Mode / Universal Trunking Mode
    Communication standard

    IEEE 802.3(Ethernet)
    IEEE 802.3u(Fast Ethernet)
    IEEE 802.11b/g/n(2.4G WLAN)

    IEEE 802.11a/n/ac(5.8G WLAN)

    Wireless SettingsIntelligent channel analysis
    Distance control 802.1x ACK time output
    Multiple SSIDs, up to 4 configurable
    BSSID
    Wireless SecurityWEP security mechanism Support 64/128/152-bit WEP security password
    WPA/WPA2 security mechanism (WPA-PSK using TKIP or AES)
    WPA/WPA2 security mechanism (WPA-EAP using TKIP)
    Hidden SSID security mechanism
    System SettingsWEB configuration (HTTP/remote login)
    Software UpgradeWEB page or TFTP to upgrade software
    User ManagementConfigurable user and password
    System MonitoringDevice and network status statistics
    LoggingProvide local log, host log, file transfer log
    Recovery SettingsRestore output default settings
    Backup FunctionsSystem configuration can be backed up to restore user configurations when needed
    Physical Characteristics
    Temperature CharacteristicsOperating temperature: 0°C to 55°C
    Storage temperature: -20°C to 70°C
    Humidity5% to 95% (typical)

    Details Images

    2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas2.4GHz 5.8GHz Gigabit White Outdoor Dual Band Signal Repeater With 4 Antennas
