    Cat6 Wifi Router 4g Lte 12V DC Power 1200Mbps With Rj45 Port

    Ask Lasest Price
    Brand Name : HUASIFEI
    Model Number : H810
    Certification : FCC/CE/ROSH
    Price : Negotiable
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 1000PCS/45 days
    Delivery Time : 7 work days
    • Product Details
    • Company Profile

    Cat6 Wifi Router 4g Lte 12V DC Power 1200Mbps With Rj45 Port

    4G Cpe Cat6 Modem Rj45 Port 12V DC Power 1200Mbps Wifi Router 4g Lte


    Specification


    ◇ PlatformMTK7628A +MT7612E
    ◇ Band/ModeTDD-LTE: B38/40/41 FDD-LTE: B1/3/5/7/8/20 WCDMA:B1/B5/B8The frequency will reflect the cost. If you have some special request on this, please mark, we will quote accordingly.
    ◇ Data service 2×CAB1+B1/B5/B8/
    B3+B3/B5/B7/
    B8/B20;
    B7+B5/B7/B8/
    B38+B38;
    B40+B40;
    B41+B41


    ◇Mobile data speed
    LTE-FDD(CAT6): Max 300Mbps (DL)/Max 50Mbps (UL)
    LTE-TDD(CAT6): Max 226Mbps (DL)/Max 28Mbps (UL)
    UMTS:
    DC-HSDPA: Max 42Mbps
    HSUPA: Max 5.76Mbps
    WCDMA: Max 384Kbps (DL)/Max 384Kbps (UL)
    ◇ TypeIndustrial 11AC Router
    ◇ Size(mm)200*170*35Cmm
    ◇ Weight(g)520G
    ◇ System memory128MB DDR2,16MB SPI
    ◇ WiFi CoverageWireless coverage to mobile phone up to 150 Meters
    ◇ Selling PointsOpenWRT System customized supported
    Support TR069TBD
    12V 1.5A
    Support Advertising,Cloud ServiceTBD
    2.4G+5.8G frequency
    Supports up to 100 users100users by wireless
    Supports frequency customizedTBD
    Support WAN/WLAN Port
    ◇ Memory
    * System memory128MB DDR2,16MB SPI
    * External memoryUSB Stick up to 32GB
    ◇ WIFI
    * Frequency Band2.4GHz+5.8G5.8G is optional
    * 802.11a/b/g/n/ac5G MT7612 up to 866.7Mbps PHY Rate2.4 G:2T2R(300Mbps );5.8G:866.7Mbps PHY Rate
    * AP FeaturesSecurity modesOpen
    WPA-PSK
    WPA2-PSK
    WPA-WPA2 Hybrid mode (Mixed Mode)
    Concurrency (FC quality for LE1.0)AP
    Independent security modes (Open,, WPA, WPA2, WAPI) for concurrency modes
    Channel of operation - same channel
    OtherQoS and PS
    WMM
    WMM-PS/uAPSD
    ERP protection
    Coexistence
    LTE coexistence (static channel selection)
    Data Switching/Forwarding
    Switching of packets amongst clients
    Support for forwarding data to and from WAN
    DNS
    ◇ Interface
    * Antenna4G/3G/2G Main antenna
    4G MIMO/3G Rx Diversity antenna
    WiFi antenna
    External
    * USBUSB 3.0USB 3.0 High Speed
    * SIM/USIM Card slotYesStandard 6 PIN SIM card interface, compliant with 3GPP 31.101 and 31.102
    * Micro-SD Card slotYes
    * RJ45 Port1WAN; 3 LAN
    * L*H*W (mm)
    *Weight(g)520G
    ◇ Button
    * PowerYes
    * ResetYes
    ◇ Other DescriptionItemRemark/Supplier
    ◇ Electrical performance spec
    * RF Power SpecClass 4 for UMTS/HSPA/LTE;
    Class 4 for GSM 850/900;
    Class 1 for GSM 1800/1900;
    Class E2 for EDGE 850/900/1800/1900

    * Power supply inputYes;12V, 1.5A
    * Power supply outputYes
    ◇Environmental reliability test condition
    * Normal Operation-10°C to +55°C
    * Restricted Operation-20°C to +55°C
    * Storage-20°C to +70°C
    ◇ Compliance
    * ROHSYES, EU RoHS
    * JATEYes
    * TELECYes
    * PSEYES
    * othersdepend on customer required

    Details Images

    Cat6 Wifi Router 4g Lte 12V DC Power 1200Mbps With Rj45 PortCat6 Wifi Router 4g Lte 12V DC Power 1200Mbps With Rj45 PortCat6 Wifi Router 4g Lte 12V DC Power 1200Mbps With Rj45 PortCat6 Wifi Router 4g Lte 12V DC Power 1200Mbps With Rj45 PortCat6 Wifi Router 4g Lte 12V DC Power 1200Mbps With Rj45 Port

    FAQ

    Q1. Can I have a sample order?

    A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

    Q2. What about the lead time?

    A: Sample needs 1-3 working days, mass production time needs 3-5 weeks based on order quantity.

    Q3. Do you have any MOQ limit?

    A: Low MOQ, 1pc for sample checking is available.

    Q4. Do your products meet our standards?

    A: Yes, almost all our products have CE,ROHS,FCC,etc.

    Q5. How to proceed an order?

    A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Then we arrange the production.

    Q6. How do you ship the goods and how long does it take to arrive?
    A: We usually ship by Ali-Logistics, DHL, UPS, Fedex, TNT, EMS, SF Express or your designated forwarder. It usually takes 3-7 days to arrive. Airline and sea shipping also optional.
    Q7. What is your payment term?
    We have Ali- pay, T/T, Visa,Western Union payment terms options, you can choose the one which is convenient or effective for you !
    Q8. Can you customized logo and packaging?
    A: Yes, OEM/ODM are acceptable. Our design team will help you design as your requirement.
