HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module

Shenzhen Huasifei Technology Co., Ltd.
Contact Now
    Buy cheap HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module from wholesalers

    Buy cheap HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module from wholesalers
    • Buy cheap HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module from wholesalers
    • Buy cheap HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module from wholesalers

    HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module

    Ask Lasest Price
    Brand Name : HUASIFEI
    Model Number : WS1699-RM520N-GL
    Certification : FCC/CE/ROSH
    Price : Negotiable
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 1000PCS/45 days
    Delivery Time : 7 work days
    • Product Details
    • Company Profile

    HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module

    HUASIFEI gigabit wifi6 router dual band 3000Mbps wireless 5g router with RM520N-GL module

    Product Description

    The 5G WiFi6 router is based on a new embedded platform to meet the growing demand for mobile devices.
    The CPE is NSA/SA dual-mode compatible for all network types worldwide, which means you can enjoy ultra-fast broadband connectivity wherever you are by simply plug-and-playing.Enjoy an ultra-fast broadband connection anywhere.
    CPE brings new ways to experience VR/AR/4K/8K streaming freely and easily. Built-in 802.11ax (Wi-Fi 6) Technology, Single CPE With built-in 802.11ax (Wi-Fi 6) technology, a single CPE delivers more wireless coverage and more bandwidth. At the same time, CPE also brings higher security, better network

    Hardware Description

    Adopt MT7981B main chip, main frequency up to 1.3GHZ; With independent MT7976CN WIFI6 chip,

    total speed up to 3000Mbps; High-speed 512 DDR3, with 256MB SPI Nand Flash
    1WAN+4LAN 1000Madaptive network port ;
    Support "one-key flashing mode", long press the reset button to enter the recovery mode;
    Built-in M.2 interface for installing 5G cellular modules;;
    External standard Nano SIM card slot ,Reserve Esim design and customize according to customer needs

    Specification

    WS1699 Hardware Specifications
    Hardware Specifications

    MT7981B+MT7976CN+MT7531AE Dual Core 1.2GHZ

    DDR3 memory 512MB

    SPI NAND FLASH 256MB

    WIFI Chip MT7976CN IEEE 802.11n/g/b/a/ac/ax,Max. 3000Mbps
    Protocol Standards IEEE802.11n/g/b/a/ac/ax,IEEE802.3/802.3u
    Wireless Rate Dual-band concurrent up to 3000Mbps
    Operating band 2.4GHz 5.8GHz
    4G 5G Modem

    5G SA Transmission Speed:2.1Gbps/900Mbps (up to ISPs)

    5G NSA Transmission Speed:2.5Gbps/650Mbps (up to ISPs)

    LTE : Down 1.0 Gbps;UP 200 Mbps

    5G NR

    NSA

    n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/

    48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79

    SA

    n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/

    48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79

    LTE

    LTE-FDD

    B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/

    66/ 71

    LTE-TDD

    B34/ 38/ 39/ 40/ 41/ 42/ 43/ 48

    UMTS

    WCDMA

    B1/ 2/ 4/ 5/ 8/ 19

    5G SA Sub-6

    5G NSA Sub-6

    LTE

    WCDMA

    DL 2 Gbps; UL 1000 Mbps

    DL 2.6 Gbps; UL 650 Mbps

    DL 600 Gbps; UL 150 Mbps

    DL 42 Mbps; UL 11 Mbps

    Output Power

    11n:17dBm±1dBm

    11g: 17dBm±1dBm

    11b: 19dBm±1dBm

    11a: 19dBm±1dBm

    11ac: 18dBm±1dBm

    11AX: 19dBm±1dBm

    Receiving sensitivity

    11N HT20 MCS7: -72dBm

    11N HT40 MCS7: -69dBm

    11G 54Mbps: -74dBm

    11B 11Mbps: -86dBm

    11A 54Mbps: -73dBm

    11AC VHT20 MCS8: -66dBm

    11AX VHT20 MCS8: -66dBm

    Antenna

    4 x 7dbi high gain omni-directional wifi antennas,

    4 x 7dbi high gain omni-directional 4G5G antennas

    Interface

    1*10/100M/1000M WAN port with automatic MDI/MDIX with LED

    4*10/100M/1000M LAN ports, auto MDI/MDIX with LED

    1*M.2

    2*SIM card

    LED Power/WIFI/4G/5G
    Button 1 Reset button,
    Power adapter DC 12/3000mA
    Maximum power consumption < 24W
    Color scheme Black
    Accessories and Packaging

    Egg separator paper tray 32*21*6cm *1PCS

    Whole box: 43.1*28.5*34.8 10PCS

    Power adapter 12V/3A *1PCS

    Super Category 5 network cable *1PCS

    Details Images

    HUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL ModuleHUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL ModuleHUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL ModuleHUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL ModuleHUASIFEI Wifi6 Router Dual Band 3000Mbps Wireless 5g Router With RM520N-GL Module

    FAQ

    Q1. Can I have a sample order?

    A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

    Q2. What about the lead time?

    A: Sample needs 1-3 working days, mass production time needs 3-5 weeks based on order quantity.

    Q3. Do you have any MOQ limit?

    A: Low MOQ, 1pc for sample checking is available.

    Q4. Do your products meet our standards?

    A: Yes, almost all our products have CE,ROHS,FCC,etc.

    Q5. How to proceed an order?

    A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Then we arrange the production.

    Q6. How do you ship the goods and how long does it take to arrive?
    A: We usually ship by Ali-Logistics, DHL, UPS, Fedex, TNT, EMS, SF Express or your designated forwarder. It usually takes 3-7 days to arrive. Airline and sea shipping also optional.
    Q7. What is your payment term?
    A:We have Ali- pay, T/T, Visa,Western Union payment terms options, you can choose the one which is convenient or effective for you !
    Q8. Can you customized logo and packaging?
    A: Yes, OEM/ODM are acceptable. Our design team will help you design as your requirement.
